Harmonic analyzer from Mader

Model 556

Category:

L III 17; L III 17a

Description

Harmonic analyzer from Mader (Images 1-4, 8 and 11-13).
new construction Mader-Ott to 556. Item on loan from the company Ott, Kempten (Images 5-7, 9 and 14-16).
Photographies to this: $ a_1 = \int y^2 dx $,   $ a_2 = \int \sqrt y\, dx $,   $ a_3 = \int \sqrt r\, d\varphi $   and   $ a_4 = \int y^2 dx $

Showcase of this model is Case number 48

References

Separataband M3 im Mathematischen Institut p. 649.

Separataband M3 im Mathematischen Institut p. 247.

Separataband M5 im Mathematischen Institut p. 517-524.

Separataband M5 im Mathematischen Institut p. 357-374.

Willers. Math. Instr. Samml. Göschen.
